Customized 2 Ports Fiber Optic Equipment 2FE EPON FTTH ONT Modem

Product Categories

SHAANXI JIZHONG ELECTRONICS SCIEN-TECH CO.,LTD.

Contact Now

Name: Customized 2 Ports Fiber Optic Equipment 2FE EPON FTTH ONT Modem
Brand: JiZhong
Price: 1 USD

Brand Name : JiZhong

Model Number : JZOG-3202

Place of Origin : China

MOQ : 1pcs

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 10000pcs per month

Delivery Time : 5 work days

Packaging Details : Outer carton box:37x35x24 Weight:6Kg per month Qtys:10pcs per carton

Wavelength : Transmitting port:1310 +/-20nm, Receiving port:1490 +/-10nm

Portocol : GPON: ITU-T G.984.1/2/3/4; EPON: 802.3-2005 and CTC EPON

GPON : download 2.488Gbit/s, upload 1.244Gbit/s;

EPON : symmetric 1Gbit/s

Output optical power : Min. 0dBm; max. +4dBm

Receiver sensitivity : -27dBm

Receiver optical power : Min. -3dBm

Size : 130x85x26mm

Contact Now

Customized 2 Ports Fiber Equipment Modem FTTH ONT 2FE EPON FTTH ONU

Data Process:

Support two-way linear speed data forwarding, support 256 MAC Address Table;

Support 802.3 SNAP and Ethernet II package, supporting 802.1P/Q priority definition, IP DSCP field, ACL definition based priority

Support tag identification,modify and add; support protocol message identify and capture

Supports ACL rule(supporting MAC/IP/TCP/UDP/ICMP /IGMP /IPv6 format )

Ethernet support adaptive or manual rate and full/half duplex

Support 802.1x certificate, STP /RSTP protocol

Traffic control based on ingress ; support QoS function

Technical Index:

Hardcase

Shell	Plastic casing		Operating temperature: 0 to 50ºC

Physical	Item Dimension:	Working	Storage temperature: -40 to 85ºC
		Enviornment
weight	0.2kg/pc	Enviornment	Operating humidity: 10% to 90%(Non-condensing)

indicator	Power/PON/LOS/LAN		Storage humidity: 10% to 90%(Non-condensing)

Port Datasheet
	Wavelength: Tx 1310nm, Rx1490nm		VLAN Tag/UNTAG

	Tx Optical Power: 0~4dBm		Q in Q VLAN

PON	Rx Sensitivity: -27dBm	Ethernet	MAC address restricion
Parameter	Two direction FEC(Forward Error	Ethernet	MAC address learning
Parameter	Two direction FEC(Forward Error		MAC address learning

	authertation: MAC/Key/LOID		two layer IPv6 transparent transmit

	Optical Fiber: 9/125 single-mode fiber		1:1 VLAN/N: 1VLAN/VLAN transparent transmit

Function
	Ethernet speed limitation		OMCI/Web UI
	Support VLAN TAG/UNTAG,VLAN		802.1ag Ethernet OAM
	conversion		802.1ag Ethernet OAM
	conversion
QoS	Support Port-based speed limitation		loop detection
	802.1p Priority	O&M	optical link supervision
	broadcast storm control		IGMP v2/v3 snooping
	flow mapping		MLD v1/v2 snooping
Security	MAC address filter		downstream VLAN switch/ transparent transmit

Operation	PPPOE/DHCP proxy test		IGMP/MLD message speed limitation

Customized 2 Ports Fiber Optic Equipment 2FE EPON FTTH ONT Modem
